AW596B
HPE Modular Smart Array P2000 G3 10GbE iSCSI Dual Controller LFF Array System
HPE Modular Smart Array P2000 G3 10GbE iSCSI Dual Controller LFF Array System
Regular price
£6,274.45
Sale price
£6,274.45
Regular price
£7,219.19
Unit price
/
per
Taxes included
In Stock - Delivery from tomorrow
FREE Delivery to most of the UK
Couldn't load pickup availability
Share
Product Description
The MSA P2000 G3 10GbE iSCSI brings the high-performance host connection with technology generally found only in higher priced arrays. The bandwidth it provides in conjunction with server consolidation is highly advantageous in shared storage configurations. Array connection to 10GbE switches that are in turn connected to 1GbE NICs is commonplace.
Main Specifications
General
| Device Type | Hard drive array |
|---|---|
| Enclosure Type | Rack-mountable - 2U |
Expansion / Connectivity
| Expansion Bays | 12 (total) / 12 (free) - 3.5" LFF |
|---|---|
| Interfaces | 2 x management - mini-USB Type B 2 x management - RJ-45 2 x SAS 6Gb/s - 26 pin 4x Shielded Mini MultiLane SAS (SFF-8088) 4 x Ethernet 10Gb |
Storage
| Maximum LUNs | 512 |
|---|---|
| HDD Array External Interface | iSCSI |
Miscellaneous
| Compliant Standards | VCCI, CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, GS, EN 61000-3-3, EN55022 Class A, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, RoHS, FCC Part 15 A, EN55024 Class A, AS/NZS, CAN/CSA C22.2 No. 60950-1-03 |
|---|
Power
| Max Supported Qty | 2 |
|---|---|
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Power Device | 2 x internal power supply - hot-plug |
| Voltage Required | AC 120/230 V - 50/60 Hz |
Environmental Parameters
| Max Operating Temperature | 40 °C |
|---|---|
| Min Operating Temperature | 5 °C |
| Sound Emission | 55 dB |
| Humidity Range Operating | 10 - 90% (non-condensing) |
Storage Controller
| Installed Qty | 2 |
|---|---|
| Cache / Buffer Size (Max) | 2 GB |
| RAID Level | RAID 0, RAID 1, RAID 3, RAID 5, RAID 6, RAID 10, RAID 50 |
| Data Transfer Rate | 600 MBps |
| Interface Type | SATA 3Gb/s / SAS 6Gb/s |
| Type | RAID (iSCSI) |
System Requirements
| OS Required | Red Hat Linux, SUSE Linux Enterprise Server, Microsoft Windows Server 2003 R2 SP2, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008 SP2, Microsoft Windows Server 2008 SP1, Microsoft Windows Server 2003 SP2 |
|---|
Storage Controller (2nd)
| Installed Qty | 2 |
|---|
Dimensions & Weight
| Width | 44.7 cm |
|---|---|
| Height | 8.9 cm |
| Depth | 55.1 cm |
| Weight | 19.2 kg |
Chassis
| Installed Devices / Modules Qty | 0 |
|---|---|
| Supported Devices / Modules Qty | 12 |
| Supported Drives | SATA-300 / SAS-2 |
