6160S8E
Lenovo TS2280 6160-H8S
Lenovo TS2280 6160-H8S
In Stock - Delivery from tomorrow
FREE Delivery to most of the UK
Couldn't load pickup availability
Share
Product Description
These tape drives are designed for the heavy demands of backup tape storage. The drives deliver robust tape reliability and performance.
Product Features
Independent tape loader and threader motors and positive pin retention: These technologies help improve the reliability of loading and unloading a cartridge and retain the pin, even if tension is dropped. An independent loader motor that is coupled with the positive pin retention causes the tape to thread with a higher level of reliability.
Graceful dynamic braking: If there is a power failure, reel motors maintain tension and gradually decelerate instead of stopping abruptly, which helps reduce tape breakage, stretching, or loose tape wraps during a sudden power outage.
Digital speed matching: These tape drives perform dynamic speed matching to adjust the drive's native data rate as closely as possible to the net host data rate (after data compressibility is factored out). This matching helps reduce the number of backhitch repositions and improve throughput performance.
Main Specifications
General
| Width | 21.3 cm |
|---|---|
| Depth | 33.2 cm |
| Weight | 4.3 kg |
| Height | 5.8 cm |
| Device Type | Tape drive - LTO Ultrium |
| Enclosure Type | External - 2U |
| Key Features | Encryption |
| Interface Type | SAS-2 |
| Recording Standard | LTO Ultrium 8 |
Expansion / Connectivity
| Interfaces | 2 x SAS 6Gb/s - 26 pin 4x Shielded Mini MultiLane SAS (SFF-8088) 1 x management - RJ-45 |
|---|
Manufacturer Warranty
| Type | Limited warranty - 3 years - on-site - response time: next business day - availability: 9 hours a day / Monday-Friday |
|---|
Miscellaneous
| Rack Mounting Kit | Optional |
|---|---|
| Included Accessories | Cleaning cartridge |
| Compliant Standards | FCC Part 15 A, ICES-003 Class A, Directive 2004/108/EC, EN 55022 Class A, VCCI Class A, KCC Class A, EMI |
Power
| Type | Power supply |
|---|---|
| Power Consumption Operational | 48 Watt |
| Voltage Required | AC 120/230 V (50/60 Hz) |
Environmental Parameters
| Min Operating Temperature | 10 °C |
|---|---|
| Humidity Range Operating | 20 - 80% |
| Max Operating Temperature | 38 °C |
| Sound Emission | 6.6 dBA |
Storage Removable
| Buffer Size | 1 GB |
|---|---|
| Capacity | 12 TB (native) / 30 TB (compressed) |
| Type | LTO Ultrium |
| Data Transfer Rate (native) | 300 MBps (1080 GBph) |
| Data Transfer Rate (compressed) | 750 MBps (2700 GBph) |
| Recording Standard | Ultrium 8 |
| Supported Tape Cartridges (Read and Write) | Ultrium 8 |
