The SN5600 smart-leaf, spine, and super-spine switch offers 64 ports of 800 GbE in a 2U form factor. The SN5600 offers diverse quad small form factor double density (OSFP) connectivity options ranging from 1 to 800 GbE and boasts a total throughput of 51.2 Tb/s, making it ideal for 800 G data center fabrics.

Features

• 64 OSFP 800 GbE ports in a 2U form factor.
• Connector-to-Power (C2P) Airflow Orientation
• Supports up to 51.2 Tb/s switching capacity.
• Delivers 33.3 Bpps wire-speed throughput.
• Breaks out to 800, 400, 200, 100, 50, 40, 25, 10, and 1 GbE.
• Built on 8x50G PAM4 lanes per port for full 400G bandwidth.
• Powered by an octacore AMD CPU.
• Includes 32 GB system memory and 80GB NVMe 3 SSD.
• Equipped with a 160 MB fully shared packet buffer.
• Comes with RJ45 management and serial ports.
• Includes USB Type 3 port for fast local access.
• Features 2 hot-swap redundant power supplies.
• Includes 5 hot-swappable redundant fans.
• Operates in 0–35°C environments.
• Runs on 200–240 VAC input at 50–60 Hz.
